A2Z EVSE Cabinet-Based Solar Storage & Charging
Up to 600 kW · 600A liquid-cooled · 800 kWh – 3 MW
On request
A2Z EVSE Mobile Solar-Storage-Charging System 5.1 kWh
Compact Portable Charger (Pulse Mode)
Dealer pricing on request
- Battery capacity
- 5120 Wh
- Min. AC output energy
- 4300 Wh
- Outputs
- AC 220V · DC 12V & 5V · USB QC3.0/PD
- Every unit electrically and physically tested before it ships
- Real people on the phone — no bots
- Ships domestically from US and Canadian warehouses
- Private label, packaging and custom lengths for dealers
Mobile 5.1 kWh solar-storage power unit with AC, DC and USB outputs and an AC EV charging cable.
- Battery capacity: 5120 Wh
- Min. AC output energy: 4300 Wh
- Outputs: AC 220V · DC 12V & 5V · USB QC3.0/PD
- Solar input: 60–450V · 2000W max
- Grid input: 220V AC · 10A
- EV charging cable: 8–16A adjustable · 240V AC · 5 m
Ideal for: dealers, distributors and OEM/whitelabel programs.
Quote-only. Request a quote for volume pricing, OEM/whitelabel and lead times.
| Battery capacity | 5120 Wh |
|---|---|
| Min. AC output energy | 4300 Wh |
| Outputs | AC 220V · DC 12V & 5V · USB QC3.0/PD |
| Solar input | 60–450V · 2000W max |
| Grid input | 220V AC · 10A |
| EV charging cable | 8–16A adjustable · 240V AC · 5 m |
| Charge / discharge | Bidirectional supported |
Can I get this with my own branding or packaging?
For dealer and distributor programs we can supply private-label housings, colours and packaging. Ask the B2B team for minimums and lead times.
Which vehicles and chargers does it work with?
Read the charger → vehicle path above: the left side plugs into the charger, the right side into the vehicle. AC, DC and V2L paths are not interchangeable. For DC fast charging, also confirm network access in the vehicle’s app.
How do I get the price list and datasheet?
Use Request a quote on this page or call the B2B line. We’ll send the datasheet, current pricing and model guidance for your market.
What warranty and after-sales support is included?
A 12-month manufacturing-defect warranty on adapters, with a real support team by phone. Commercial EVSE warranty terms are confirmed in each quote.
Do chargers support OCPP or app control?
Commercial DC stations support OCPP 1.6 / 2.0. Wall-mounted AC models offer Wi-Fi, 4G, Bluetooth and RFID options depending on configuration.
Support every step of the way
Defect coverage
If a product fails from a manufacturing defect, we repair or replace it — and handle the claim quickly.
Training & materials
Counter guides, product imagery and connector education so your team recommends the right part.
Engineering support
Configuration help for custom lengths, regional plugs and commercial site projects.
Related products
A2Z EVSE Home Solar Storage & Charging
5 kWh / 10 kWh / 15 kWh / 20 kWh · 5 kW / 8 kW / 10 kW / 10 kW
On request
Need another combination?
Adapters across NACS, CCS1, CCS2, CHAdeMO, GB/T, Type 2 and J1772 — plus custom pairings, lengths and regional variants.
